LED Series // LED Séria

Titan Tube™ LED FP1

none
The ultimate film lighting tube for TV, cinema and photography.

72W power, 16 pixel segments, 180° beam angle, IR, App controlled, wired and wireless (CRMX) DMX, built-in rechargeable LG battery, IP65. Includes stand, 2 eye bolts, 2 holders.

Film Lighting Tube | Titan Tube was especially designed for the Film, Broadcasting and Cinema industries. Optimized for an ultra-high TLCI, a very high CRI and peak brightness, colors as well as Hue, Saturation and Intensity can be set directly on the tube. In addition, the Titan Tube now accepts wired DMX via a special power/data combination cable.

Technical Data:

flipInY
  • Optical:
  • Control:
  • Electrical:
  • Construction:

Colors:Red, Green, Blue, Mint, Amber
Total LED power:72 W
Maximum power draw:48 W
TLCI:≥96
CRI:≥96
Luminous flux:2900Lm
Emittance @1m:785Lx
Strobe:0-25Hz
Beam Angle:120˚
Field Angle:180˚
Pixels:16

Backside Display:with HSI control
Infrared
Wireless Modules:865-870MHz | 902-928MHz | 2.4GHz
Range:300m | 330 Yards
DMX:Wired + Wireless (CRMX & W-DMX)

Battery:LG Chem Lithium-ion
Battery Lifetime:70% after 300 cycles
Battery Runtime:Up to 20 hours
LED Lifetime:50.000 Hours
Charging time (nominal):3 Hours
Input Voltage:24V 2A

Housing:Polycarbonate, metal endcap
IP Rating:IP65
Relative humidity:0-100%
Operating Temperature:0-40 ˚C | 32-104 ˚F
Weight:1.35kg |3Lbs
Dimensions:Ø42 x 1035mm | Ø1.6” x H40.7”

Accessories

This light head works with following Accessories:

All
Soft box
WingPlate
SnapBox DoPChoice
WingPlate
SnapBag DoPChoice
WingPlate
FP1-WP
WingPlate
FP1-PB
PowerBox
FP1-CHR
Charger
FP1-CHRCSE
Charging case
AX1-EBLT
Eyebolt (2 pces Included)
AX1-H
Holder (2 pces included)
AX1-STD
Stand (included)
AX1-BLT
Spigot
